LEVITON 9530-P Straight Blade Power Plug 30 A, 125 V, Power Plug
lev9530p
LEVITON 9530-P Straight Blade Power Plug 30 A, 125 V, Power Plug
Price
$194.98
/ EA
Inventory
Available for backorder
Manufacturer:LEVITON
Manufacturer #:9530-P
Description
Industrial grade straight blade plug made of super tough nylon. Solid brass blades/contacts and steel, zinc plated assembly screws. Leviton's heavy duty industrial power plugs offer superior performance, long-lasting reliability and features that are backed by a 10-year warranty.
Specifications
| Brand Name | Leviton | Sub Brand | Straight Blade Plugs and Conn |
| Item Name | Straight Blade Power Plug | Type | Angled |
| Number of Wires | 3 | Number of Poles | 2 |
| Voltage Rating | 125 V | Amperage Rating | 30 A |
| Conductor Size | 10-4 AWG | Color/Finish | Black |
| Cord Size | 0.625 - 1.375 in | Terminal Connection | Screw Terminal |
| NEMA Rating | 5-30P | Material | Super Tough Nylon/Plastic |
| Grounding | Grounding | Mounting Type | Cable |
| Dimensions | 2.76 in W x 1.89 in D x 4.37 in H | Environmental Conditions | -40 to 60 °C |
| Standards | ANSI C-73, CSA C22.2 No. 42 File Number 152105, NEMA WD-1, WD-6, NOM 057 Certified, UL 498 File Number E13399 | Application | For Industrial use |
| UPC | 078477809853 |
Packages
| 1 - Unit | 10 - Crate | 900 - Pallet |
