lev5371ig
LEVITON 5371-IG Receptacle isolated ground flush-mount 30A 125V
lev5371ig
LEVITON 5371-IG Receptacle isolated ground flush-mount 30A 125V
Price
$70.22
/ EA
Inventory
Available for backorder
Manufacturer:LEVITON
Manufacturer #:5371-IG
Description
Industrial-grade heavy-duty flush mount single receptacle. Nylon face and body. Brass double-wipe line contacts. Galvanized steel strap. Side wired. Straight blade wiring. 2 HP AC horsepower rating. 2-pole. Isolated-grounding, 3-wire. NEMA-5-30R. Withstands 2000 V per UL498 dielectric voltage. Full rated current limiting. Rated V-2 per UL94 flammability. -40 to 60°C operating temperature. Terminal accommodates up-to 4 AWG. Ratings are permanently marked on device. Applicable for factories, schools, hospitals and commercial office buildings.
Specifications
| Brand Name | TRADITIONAL DEVICES | Sub Brand | RESIDENTIAL RECEPTACLES |
| Type | Power Receptacle | Size | 3.75 H x 2.50 W x 2.10 D IN |
| Voltage Rating | 125 V | Amperage Rating | 30 A |
| Number of Poles | 2 | Number of Wires | 3 |
| Connection Type | Side Wired | NEMA Rating | 5-30R |
| Material | Thermoplastic | Color | Orange,Orange |
| Dielectric Strength | 2000 (Min.) | Grounding | Isolated Ground |
| Mounting Type | Box | Temperature Rating | -40 To 60 °C |
| Environmental Conditions | Flammability (Rated V-2 Per UL94) | Standards | NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA C22.2 No. 42 (File 152105);UL Listed 498 (File E13399) |
| Application | Commercial | UPC | 078477823491 |
Packages
| 1 - Unit | 10 - Crate | 1680 - Pallet |
