lev3720
LEVITON 3720 Receptacle single locking industrial 2P 3W 347V 20A black
lev3720
LEVITON 3720 Receptacle single locking industrial 2P 3W 347V 20A black
Price
$89.74
/ EA
Inventory
Available for backorder
Manufacturer:LEVITON
Manufacturer #:3720
Description
Industrial grade single locking receptacle.
Specifications
| Brand Name | Leviton | Sub Brand | V-0-Max™ |
| Item Name | Locking Single Receptacle | Type | Covers |
| Grade | Industrial | Size | 4.6" |
| Voltage Rating | 347 V | Amperage Rating | 20 A |
| Number of Poles | 2 | Number of Wires | 3 |
| NEMA Configuration | NEMA L24-20R | Connection Type | Screw |
| NEMA Rating | L24-20R | Conductor Size | 14-8 AWG |
| Material | Nylon, Ultramid Face | Color | Black |
| Finish | Clear | Wiring Configuration | Back and Side Wired |
| Dielectric Strength | 2000 V | Contact Material | Brass |
| Mounting Type | Inner Lying | Temperature Rating | -40 °C to 60 °C |
| Standards | NEMA (WD-6), ANSI (C-73), NOM Certified (057), CSA C22.2 No. 42 (LR-406), UL498 (E13399), UL Fed Spec WC-596 (E13399) | Application | Industrial |
| UPC | 785007765281 |
Packages
| 1 - Unit | 10 - Box | 30 - Crate | 2640 - Pallet |
